14 x 14 x 1.2mm Carbide Spur Knives, Box of 10

Description

The INKS410 provides a box of 10 solid carbide 14 x 14 x 1.2mm spur knife inserts for Schmidt indexable insert heads designed for this thinner spur geometry. At 1.2mm thickness versus the 2.0mm of INKS414, the INKS410 spur knife is a thinner insert for heads where the insert seat geometry specifies the narrower profile — a distinction that makes INKS410 and INKS414 non-interchangeable despite the same 14 x 14mm face dimensions. Spur inserts score panel surfaces or establish shoulder lines in grooving and rebating operations to prevent surface tear-out in face-sensitive materials. Square 14 x 14mm spur knives can be indexed to expose fresh edges as they wear. Sold in boxes of 10 for production stocking. The thin 1.2mm profile is specific to certain insert head seat configurations — confirm the head model specifies INKS410 (not INKS414) before ordering.
